PRODUCT DESCRIPTION
● The labeling head can choose famous brand servo motor.realize the reaclosed loop control, the high precision subdivision, all these are designecfor the high precision.
● Double-stage clutch design makes label tension more stable and easy to improve labeling accuracy.
● The control system uses Mitsubishi PLC and famous brand touch screer
● Belt conveyor suitable for all kinds of flat products labeling.Can chooseproduct entrainment mechanism or labeling mold to achieve higherlabeling precision.
● Feeding device can be selected ,Suitable for leaflets, envelopes, greeting cards, cartons and other products
● Fully enclosed frame and SCHMEASAL safety switch can be selected
.jpg)
.jpg)
Model | MD-220 |
Labeling speed | 10-40 meters/min |
Labeling accuracy | +1mm |
Max label width | 100mm( can be customized ） |
Applicable product size | 30-80mm( can be customized ） |
Inner diameter of paper | 76mm |
Outer diameter of paper | 300mm |
Air source | 4-6KG 30L/min |
Dimension | 2000*800*1500mm |
Voltage | 220V 50Hz 2000W |
Weight | 250KG |
